Equipment We Use
Leakalyzer
The Leakalyzer enables rapid determination of a pool’s water loss. It measures water level changes to the 10,000th of an inch, enabling leaks to be identified in as little as 5 minutes. The Leakalyzer is so sensitive that water loss of less than a gallon from a 20' x 40' pool is readily indicated.
The Leakalyzer also provides a calculation of how this measured water level change would impact the pool in inches and gallons of water lost per hour or per day.
This screen uses the measured water level change to indicate rate of water loss in inches or gallons per hour... or per day.
The benefits using the Leakalyzer also include:
- Provide "Leak Status Certifications" for pool owners, insurance companies and Realtors.
- Confirm a pool’s leak status before investing time in extensive leak location procedures.
- Confirm leaks have been fixed at the completion of repair thus avoiding expensive "call-backs."
- Compare pump-on to pump-off water loss while at the pool to better direct leak location activities.
Pressure Induction Equipment
Using customized equipment supplied by Anderson Manufacturing Company Inc. we are able to do most pressure testing without destructive cutting and patching of existing plumbing.
Listening Devices
We use the listening devices which are specially designed to pick up vibrations underground. They allow us to accurately locate plumbing leaks by sensing the "sound" air makes when escaping from a leak into saturated soil. The two listening devices we use have proven to be the best available for the swimming pool industry.
Diving Equipment
Diving Equipment used for Leak Detection.
Super Snorkel Tank-less Dive Unit
This completely filtered, oil-less compressor operated dive unit allows us to breath underwater without the problems and expenses of cumbersome tanks. We don't need to worry about refilling tanks before a job, or scratching or denting the pool when getting in or out.
Pool Diver - Dry Suit
We extend our pool repair season with this rugged, easy to use dry suit designed with the specific needs of the pool industry in mind.
FEATURES
- Heavy-duty 210 Denier nylon material is puncture and abrasion resistant
- Zipper protector assures trouble free operation.
- Neck and wrist seal protectors insure continued water tight seal
- Attached dive boots keep feet dry and warm.
- Reinforced knee and seat pads provided added durability.
- Front zipper allows self-donning.
- Wear over street clothes for added convenience.
- Side arm and crotch gussets provide added freedom of movement.
Vinyl Leak Detector
Leak Detector
Leak Detection Richmond Hill - Vinyl 4The LeakTrac 2200 utilizes proven technology to find vinyl liner leaks fast . . . without dye . . . without draining the pool . . . and without getting into the water. The LeakTrac 2200 eliminates the frustrating, expensive and time consuming task of visually inspecting every inch of a liner. While standing on the deck we are able to first establish a leaks general area, then pinpoint even the smallest leaks in minutes. This technology is effective in any water containing vessel with an electrically insulating shell, (vinyl, fiberglass, acrylic, etc.)
HOW IT WORKS:
The sophisticated, but simple to use device puts a small electrical charge into the pool water. This charge seeks to make a connection to the ground. Since the pool liner is a good electrical insulator, the only ground connections are through conductive penetrations in the liner. The LeakTrac detects electrical current flow in the water as it seeks these ground connections, and produces audible signals that lead us to the exact location of the leak.
SeeSnake® nanoReel Inspection Camera System
We use The SeeSnake® nanoReel which opens up new possibilities in long run small diameter inspection jobs. Applications where only bore scopes could reach can now be inspected using the nanoReel. Boiler Tubes, Supply Lines, Sprinkler Systems and a wide array of specialty applications can all be inspected using the nanoReel.
FEATURES
- Small Diameter and Tight-Turn Radius camera allows 1" lines up to 85 feet to be inspected.
- Lightweight and Compact unit allows for easy transport and efficient storage.
- Multiple Monitor Compatibility allows us to use the nanoReel with your existing SeeSnake monitor or the micro CA-300 and microEXPLORER™ Digital Inspection Cameras.
- Interchangeable Drums let us change out the inner drum depending on the application. We choose from:
- L100 and L100C – 1 1/2 to 4 inch lines with a stiffer push cable allowing us to inspect lines up to 100 feet.
- D30 and D65S – Small diameter with tight turns, 1 1/2" to 3" P-Traps, toilet traps for lines up to 65 feet.
- N85S – Ultra small diameter lines 1" to 2" with tight turns for specialized applications.
SPECIFICATIONS
- Camera Head: 0.62" (15.5mm)
- Cable Length: 85' (25m)
- Cable Diameter: 0.25" (6.3mm)
- Line Capacity: 1" to 2" (19 – 50mm)
- Weight: 9.5 lbs. (4.1 kg)
- Length: 13.25" (33.7 cm)
- Width: 6.6" (16.8 cm)
- Height: 17.5" (44.5 cm)
- Resolution: 510 x 496 NTSC
- Sonde: 512Hz
